PERFORMANCE
CHARACTERISTICS
Data capture
options 1D standard range
scan engine; 1D extended range scan engine; omni-directional imaging
engine reads 1D and 2D symbols omni-directionally, and captures images
and signatures; DPM engine reads a wide variety of DPM marks including
data matrix marks applied by dot peening, laser etching, molding,
stamping or casting methods to multiple substrates such as metal,
plastic or glass
Expansion SD/MMC card Memory (Flash/RAM) 64 MB/64 MB (Win CE); 64 MB/128 MB (Win Mobile) Operating system (OS) Microsoft Windows CE 5.0 Core Version, Microsoft Windows Mobile 5.0 Premium Processor (CPU) Intel® XScale™ Bulverde PXA270 624 MHz processor Windows CE yes Windows Mobile yes |
|
PHYSICAL
CHARACTERISTICS
Dimensions (HxWxD) 7.6 x 3.6
x 9.1 in.
(19.3 x 9.1 x 23.1 cm) H x W x D
Display resolution 3.8 in. QVGA mono or color (Win CE); 3.8 in. QVGA color only (Win Mobile) Display type Backlit color Keyboard 28, 43 and 53-key; terminal emulation (5250, 3270, VT) Weight 25 oz. (709 g) (includes battery, scanner and radio) |
|
POWER
Main battery
Removable, rechargeable
Li-Ion; 7.2 V; 2200 mAh battery pack; 15.8 Wh
|
|
REGULATORY
SPECIFICATIONS
EMC FCC Part 15 Subpart B, EN 301 489-7, IEC 60601-1-2, EN 55024, EN 301 489-17, EN 55022, EN 301 489-1, ICES 003 Class B, EN 61000-3-2, EN 61000-3-3 Electrical safety UL 60950-1, CSA C22.2 No. 60950-1, EN 60950-1, IEC 60950-1 Environmental RoHS Directive 2002/95/EEC Laser safety2 EN 60825-1, IEC 60825-1, 21CFR1040.10 RF exposure 787,788,789,2835 Radio FCC Part 24, EN 301 511, FCC Part 22, EN 301 893, EN 300 328 |
|
USER
ENVIRONMENT
Charging temperature 32° to 104° F (0° to 40° C) Drop specification Multiple 6 ft. (1.8 m) drops to concrete the operating temperature range Electrostatic discharge (ESD) +/- 15 kVDC air discharge; +/- 8 kVDC direct discharge; +/- 8 kVDC indirect discharge Environmental sealing IP64 (electronic enclosure, display, keypad) Humidity 5 to 95% non condensing Operating temperature -4° to 122° F (-20° to 50° C) Storage temperature -40° to 158° F (-40° to 70°) Tumble specifications 2,000 1 m. tumbles at room temperature (4,000 hits) |
|
WIRELESS
DATA
COMMUNICATIONS
Antenna Internal Data rate 802.11a: up to 54 Mbps, 802.11b: up to 11 Mbps, 802.11g: up to 54 Mbps Frequency range 802.11a - 5 GHz, 802.11b - 2.4 GHz, 802.11g - 2.4 GHz Output power 100 mW international, 100 mW US WLAN 825 WPAN (Bluetooth Support) Bluetooth v1.2 with BT Explorer |
