Specifications
Light source 630nm
Visible Red LED
Optical system 2048 pixel
CCD(Charge-coupled device)
Depth of scan field 0 – 600 mm(Code 39,
PCS = 90%, 20mils)
Scanning width 160 mm at contact
Scan speed 450 scans/sec
Current - sleep mode
25 mA @ 5VDC
Resolution 0.1 mm (4mils) Code39, PCS =
90%, on contact
Print contrast 30% or more
UMC UL,FCC
Class B,CE
Scanning angle Front: 60° Rear: 60° Yaw:
75°
Decode capability Autodiscriminates all
standard one-dimension barcodes; other symbologies can be ordered
optionally
Cable - universal type
Coiled 2.5 m
Beeper operation 7 tones or no beep
Indicator Green & Red LED
Cushion material
Double injection
Length 164 mm
Width-handle 30 mm
Width-head 78 mm
Depth-handle 56 mm
Depth-head 35 mm
Weight 176 g (cable not included)
Cable - K/B wedge
Coiled 2.5 m
Connector type RJ-45 phone jack connector
Case material ABS (over molded at contact
pointed)
Input voltage 5 VDC ± 0.25V
Shock resistance
0° to 50°C (32° to 122°F)
Power - operating 800mW
Power - standby 350 mW
Current - operating 160 mA @ 5 VDC
Current - standby 70 mA @ 5 VDC
DC transformers
Class 2; 5VDC @ 450 mA
Storage -20° to 70° (-4° to 158°)
Humidity 5% to 90% relative humidity,
non-condensing
Light level Up to 70000 Lux
Shock 1.5m drop onto concrete
Programming method Manual (reading special
barcode) DOS command through RS-232, Windows configuration program
Contaminants
Sealed to resist airborne particulate contaminants
Program upgrade
Enabled by build-in flash memory
Programmable characteristics
Code type selection,
check digit selection Decoding option Transmitted character delay,
Header selection, trailer selection, message suffix, good read beep
tone and volume, scanner trigger selection Keyboard emulation type
(intermessage delay, keyboard type and keyboard language).Serial
interface type (ACK/NAK, Xon/Xoff, RTS/CTS, good read LED control,
start/stop bits)
