Specifications
PHYSICAL CHARACTERISTICS
Color
Twilight black, Cash register white
Corded
Yes
Dimensions
6 in. H x 2.5 in. W x 3.34 in. D 15.2 cm H x 6.3 cm W x 8.4 cm
Handheld
Yes
Power source
Host power or external power supply; depends on host type
Voltage and current1
5 volts +/- 10% at 130 mA typical, 175 mA max
Weight
5.15 oz./146 gm
PERFORMANCE
CHARACTERISTICS
Decode capability
1D, See data sheet for full list of supported symbologies
Scan Rate
100 scans per second typical
Depth of field
From contact to 17 in./43 cm on 100% U.P.C./EAN symbols
Interfaces supported
Synapse, Keyboard wedge, IBM, RS-232, USB, Wand
Minimum resolution2
20% minimum reflective difference
Pitch3 +/-65 degrees
Roll (Tilt) 4
1 +/-30 degrees
Scan
pattern Single line
Skew (Yaw)5
3 +/-60 degrees
Technology
Laser
NOTICES AND DISCLAIMERS
Notices and Disclaimers6
See footnote.
REGULATORY SPECIFICATIONS
EMC
FCC Part 15 Class B, ICES 003 Class B
Electrical Safety
UL 60950-1, C22.2 No. 60950-1, EN 60950-1, IEC 60950-1
Environmental
RoHS Directive 2002/95/EEC
Laser Safety7
EN 60825-1, IEC 60825-1, 21CFR1040.10
USER ENVIRONMENT
Ambient light immunity
Immune to direct exposure of normal office and factory lighting
conditions, as well as direct exposure to sunlight
Drop specifications
Unit functions normally after repeated 5 ft./1.5 m drops to concrete
Environmental sealing
IP43
Operating temperature
Operating temperature 32° to 122° F/0° to 50° C
Storage temperature
-40° to 158° F/-40° to 70° C
1 Does not
include cable.
2 Refers to 100% UPC
bar code (80% contrast) located 4 in./10 cm. from the scanner nose.
3 Pitch: Controlled by
dropping or raising the wrist
4 Roll (Tilt):
Controlled by rotating the wrist clockwise or counterclockwise
5 Skew (Yaw):
Controlled by rotating the wrist from left to right or vice versa
6 Specifications are
subject to change without notice.
