Specifications
PHYSICAL CHARACTERISTICS
Color
Twilight black, Yellow
Corded
Yes
Dimensions
7.34 x 4.82 x 2.93 in. (18.65 x 12.25 x 7.43 cm) H x W x D
Handheld
Yes
Power
source Host power or external power
supply; depends on host type
Weight
12.56 oz. (356 g)
PERFORMANCE CHARACTERISTICS
Decode
capability 1D, See data sheet for full
list of supported symbologies
Depth of
field 4 in. to 45 ft (10 cm to 13.7m); range dependent on size of barcode
Interfaces
supported Synapse, Keyboard wedge, IBM, RS-232, USB, Wand
Pitch1
± 65°
Roll (Tilt) 2
± 10° from normal
Scan
pattern Single line
Skew
(Yaw)3 ± 60°
Technology
Laser
NOTICES AND DISCLAIMERS
Notices and Disclaimers4
See footnote.
REGULATORY SPECIFICATIONS
EMC
EN 55024, EN 61000-3-2, ICES 003 Class B, EN 61000-3-3, FCC Part 15 Class B, EN 301 489-17, EN 55022, EN 301 489-1
Electrical
Safety EN 60950-1, C22.2 No. 60950-1, UL 60950-1, IEC 60950-1
Environmental
RoHS Directive 2002/95/EEC
Laser Safety7
EN 60825-1, IEC 60825-1, 21CFR1040.10
USER ENVIRONMENT
Ambient
light immunity mmune to direct exposure of normal
office and factory lighting conditions, as well as direct exposure to
sunlight: Indoor: 450 ft. candles/4,842 LUX Outdoor: 4,000 ft.
candles/43,040 LUX
Drop
specifications Unit functions normally after repeated 6.5 ft./2 m drops to
Environmental sealing IP65
Operating
temperature -22° to 122° F/-30° to 50° C
Storage
temperature -40° to 158° F/-40° to 70° C
1 Pitch: Controlled by dropping or raising the wrist
2 Roll (Tilt): Controlled by rotating the wrist clockwise or counterclockwise
3 Skew (Yaw): Controlled by rotating the wrist from left to right or vice versa
4 Specifications are subject to change without notice.
