Specifications
Mechanical
Height 6.0" /15.2 cm
Width 6.5" /16.5 cm
Depth 4.3" /10.8 cm
Weight 3.5 lbs./1.6 g
Optical
Sweep
- Scan
lines: 18
- Rate:
1, 350 scans/sec.
- Depth-of-field:
8.0" /20.5 cm
- Read
height: 6.0" /15.2 cm
Presentation
- Scan
lines: 20
- Rate:
1, 500 scans/sec.
- Depth-of-field:
7.0" /18.0 cm (VS1000 enhanced)
5.0"
/12.8 cm (VS1000 standard & VS1200)
- Read
height: 11.5 cm /4.5"
Environmental
Temperature rating
- Operating:
50° to 104° F /10° to 40° C
- Storage:
-40° to 158° F /-40° to 70° C
Humidity
5 to 95% NC
Electrical
AC Power requirements
- 100-250
VAC, 50-60 Hz
- 6.4
Watts (nominal), 9.7 Watts (maximum), 4.4 Watts (sleep mode)
Decoding
Capability
The VS1200 reads the
UPC code family with Edge™ decoding sosftware. When the VS1200 is
programmed to read one additional industrial code, Adaptive™ decoding
software replaced Edge.
The VS1000 reads up to
three industrial codes in addition to the UPC code family, and uses
Adaptive decoding software.
UPC A, E /EAN 8, 13 /JAN
8, 13
- with
Edge (VS1200 only)
- with
P2/P5 add-ons (standard on VS1000 – excluding IBM I/Fs; optional on
VS1200)
Industrial
Codes
- Code
128
- Code
39 with Stitching (VS1000 only)
- ITF
(Interleaved 2 of 5)
- MSI
/Plessey (VS1000 only)
Communications
VS1200
- IBM
468x /469x
- OCIA
(PSC &NCR)
- OCIA
/RS232 (dual interface cable)
- RS232
- 6-bit
- Multidrop
(MDL)
- Keyboard
Wedge
- peripheral
port for undecoded scanner
VS1000
- IBM
468x /469x
- OCIA
(PSC &NCR)
- RS232
- 6-bit
- Wand
Emulation
- Keyboard
Wedge
Safety and Regulatory
Electrical
- AS
3260 (Australia)
- EN60
950 (T?V Europe)
- Korea
Agency
- MITI
T-Mark (Japan)
- UL
1950 (USA)
- cUL
C22.2 No.950-M89 (Canada)
Emissions
- FCC
part 15 subpart j, Class A (USA)
- AS/NZS
3548 (Australia/New Zealand)
- VCCI-1
(Japan)
- VDE
Class B, EN 55022-B (Europe)
Laser
classification
- CDRH
Class IIa (USA) (CAUTION Laser Radiation – do not stare into beam)
- IEC
60825 Class 1 (Europe)
Other
EAS compatibility
The optional integrated
antenna works with Checkpoint Counterpoint IV, V and subsequent models
(available from Checkpoint Systems).
